FEATURES

Programmable Digital DC Servo
Medium Aluminum Case
Super Silky Double Ball Bearing
High Strength Titanium Gear

PRODUCT SPECIFICATIONS

Voltage    4.8V ~ 8.4V   Direction    CCW
Gear Material    Titanium   Temperature    -15°C ~ +70°C
Pulse Width    500 ~ 2500 µSec   Refresh Rate    1520 µS / 333Hz
Dimension    40*20*42.3 mm   Motor Type    DC
Bearing    2BB   Dead Band    4 µSec
Net Weight    63 g   Gear Spline    25T-ɸ5.92 mm
Case Material    AL+Plastic   Travel Angel    180° ± 10°
Wire    JR 360mm / 22AWG   Wire Color    Black | Red | White

Operating Speed    Stall Torque

0.230 sec/60° @4.8V    13.0 kg·cm (180 oz·in) @4.8V
0.210 sec/60° @6.0V    15.0 kg·cm (208 oz·in) @6.0V
0.185 sec/60° @7.4V   18.0 kg·cm (248 oz·in) @7.4V
0.170 sec/60° @8.4V    20.0 kg·cm (278 oz·in) @8.4V
